A-8
FS-1000/1000+
6. MP tray feeding, A4 and others (excluding Legal size) [FS-1000+]
MOTORN
(Main motor)
MHVDR
(Main charger)
THVDR
(Transfer charger)
MPFSOL
(MP feed clutch)
RESDRN
(Registration clutch)
LDEN
(Laser diode)
BIAS
(Developing bias)
ERASPW
(Eraser lamp)
PLGDRN
(Polygon motor)
JAMR
(Registration sensor)
JAMO
(Exit sensor)
COUNT
(Total counter)
0 (s) 5 10 15 20
1000
1000
1588
1900
1800
1800
1800
6737
6737
6737
6737
7040
13720
10428
10623
16220
16220
14076
12679
16220
6059
5786
5591
6305
5837
6425
1222
6508
6467*
VSREQ(1800)
2203
4758
8883
9239
100
1468
Drum speed: 72.00 mm/s
Paper feeding speed: 132.34 mm/s
Printing speed: 12.40 ppm
11345
11498*
*: Varies depending on paper size.
: Jam detection timing
7497
2592
6661*
VSREQ (6637)
9595
11304*
