A-5
FS-1000/1000+
MOTORN
(Main motor)
MHVDR
(Main charger)
THVDR
(Transfer charger)
MPFSOL
(MP feed clutch)
RESDRN
(Registration clutch)
LDEN
(Laser diode)
BIAS
(Developing bias)
ERASPW
(Eraser lamp)
PLGDRN
(Polygon motor)
JAMR
(Registration sensor)
JAMO
(Exit sensor)
COUNT
(Total counter)
0 (s) 5 10 15 20
1000
2000
8727
16927
*
16864
16927
15997
13787
12987
13387
14787
19714
20114
18464
22714
9507
10720
9270
3298
2780
3510
VSREQ(2510)
3993
3033
7060
8060
100
3510
Drum speed: 60.00 mm/s
Paper feeding speed: 60.00 mm/s
Printing speed: 8.92 ppm
10237
10237
11150
22714
22714
*: Varies depending on paper size.
: Jam detection timing
10200
*
4423
10025
10137
VSREQ (9237)
10200
9760
3. MP tray feeding, Legal size [FS-1000]
