Kyocera FS-1000 Plus [58/163] Fuser unit mechanism

4-13

FS-1000/1000+

1 Heat roller

2 Idle gear Z34

3 Exit gear Z23

4 Idle gear Z18

5 Heat gear Z33

6 Press roller

7 Heater lamp

8 Thermal cutout

9 Separator(s)

0 Thermistor

! Exit pulley(s)

@ Lower exit roller

Fuser unit mechanism

Figure 4-1-11 Fuser unit mechanism
