FS-1000/1000+
1-3
1-1 Printer specifications
1-1-1 Specifications
(1) Engine
Item FS-1000 FS-1000+
Print method
Print speed (when printing
multiple page)
Resolution (dpi)
Smoothing
First print
(A4 or letter, 23 °C),
depends on input data
Warm-up time at 23 °C
Maximum duty cycle (A4)
Process unit life expectancy
Developing
Laser diode
Main charger
Transferring
Separation
Drum cleaning
Drum discharging
Fuser
Paper
Capacity of paper feed trays
(80 g/m
2
[0.11 mm thickness])
Capacity of output trays
(80 g/m
2
[0.11 mm thickness])
Electrophotography laser scan
10 pages/min.
600 horizontal/600 vertical
KIR
(2,400 horizontal/600 vertical)
15 seconds or less
(42 seconds or when less
reverting from sleeping)
25 seconds
100,000 pages of printing or 3
years, whichever reached first
Mono component developer
Visible laser
Scorotorn positive charging
Negative charger roller
Curvature separation
Blade
Eraser lamp (LED array)
Heat roller and press roller
Plain paper: Legal to A5
Cassette: 250 sheets,
MP tray: 50 sheets
Face-up: 30 sheets,
Face-down: 150 sheets
←
12 pages/min.
←
←
←
←
←
←
←
←
←
←
←
←
←
←
←
←
