1-4
FS-1000/1000+
(2) Controller
(3) Weight and dimensions
Item FS-1000 FS-1000+
CPU
System ROM
Font ROM
Optional font ROM
(Dip socket)
Main (Video) RAM
Additional RAM (DIMM slot)
Host interface Parallel:
Serial :
KUIO-LV :
Page description language
Standard emulation modes
PowerPC401B2/75MHz
4 MB MASK DIMM
2 MB (16 M bit × 1)
1 MB (Optional KPDL2
Upgrade kit)
4 MB (16 M bit × 2)
Max. 132 (4 + 128) MB (16/32/
64/128 MB DIMM × 1 slot)
High-speed, bidirectional
(IEEE1284)
RS-232C/RS-422A, Max.
speed: 115.2 Kbps (optional
serial interface board IB-10E)
KUIO-LV (3.3 V)
Prescribe 2e
PCL6, Diablo 630, IBM
proprinter X24E, Epson LQ850,
Line printer, KPDL2 (Optional)
←
←
←
←
←
←
←
←
←
←
←
Item FS-1000 FS-1000+
Main unit Width:
Height:
Depth:
Weight:
(excl. protrusions)
37.76 cm (14.9 inches)
22.2 cm (8.7 inches)
37.45 cm (14.7 inches)
9.5 Kg (20.94 lb.)
←
←
←
←
