3-9
FS-1000/1000+
3-1-4 Updating the firmware
The printer accepts update of the system firmware sent through the parallel interface. A PC that is
connected to the printer’s parallel interface and capable of running in DOS mode is required for this
purpose.
Updating the firmware is implemented by directly downloading the new firmware data for rewriting
the flash memory chip in the printer.
(1) Firmware data format
Kyocera supplies the data to be downloaded in the following file format:
CAUTION Do not turn off printer power while data are being downloaded (approximately
one minute).
Identifies...
1 de: Engine firmware data*
ds: Controller (system) firmware data
dm: Operation panel message data*
2 49: FS-1000
88: FS-1000+
3 Version of data (2 to 4 digits)
4 dat: Engine/controller firmware data*
dan: Panel message data for Danish*
swe: Panel message data for Swedish*
ita: Panel message data for Italian*
spa: Panel message data for Spanish*
*: These are listed for reference purpose and not applicable for models FS-1000/1000+.
ds8844.dat
123 4
