A-3
FS-1000/1000+
Timing charts
1. Cassette feeding, Legal size [FS-1000]
MOTORN
(Main motor)
MHVDR
(Main charger)
THVDR
(Transfer charger)
FEDDRN
(Feed clutch)
RESDRN
(Registration clutch)
LDEN
(Laser diode)
BIAS
(Developing bias)
ERASPW
(Eraser lamp)
PLGDRN
(Polygon motor)
JAMR
(Registration sensor)
JAMO
(Exit sensor)
COUNT
(Total counter)
0 (s) 5 10 15 20
1000
3913
2000
8727
9690
*
10640
16417
*
16354
16417
22204
22204
15487
13277
12477
11877
19204
19604
17954
22204
9515
9077
VSREQ (8727)
10210
8760
2788
2450
3000
VSREQ(3000)
3483
2688
6550
7550
100
3000
*: Varies depending on paper size.
: Jam detection timing
Drum speed: 60.00 mm/s
Paper feeding speed: 160.00 mm/s
Printing speed: 8.92 ppm
9727
9627
9690
9415
9727
14277
