A-4
FS-1000/1000+
MOTORN
(Main motor)
MHVDR
(Main charger)
THVDR
(Transfer charger)
FEDDRN
(Feed clutch)
RESDRN
(Registration clutch)
LDEN
(Laser diode)
BIAS
(Developing bias)
ERASPW
(Eraser lamp)
PLGDRN
(Polygon motor)
JAMR
(Registration sensor)
JAMO
(Exit sensor)
COUNT
(Total counter)
0 (s) 5 10 15 20
1000
3851
2000
7900
8651
*
14613
*
14550
14613
13683
12450
11500
11900
13450
17400
17800
16150
20400
8688
8250
VSREQ (7750)
9321
7721
2743
2350
2938
VSREQ(3000)
3421
2688
6550
7550
100
2938
Drum speed: 60.00 mm/s
Paper feeding speed: 160.00 mm/s
Printing speed: 10.17 ppm
8838
8650
8651
8588
8900
9813
20400
20400
*: Varies depending on paper size.
: Jam detection timing
2. Cassette feeding, A4 and others (excluding Legal size) [FS-1000]
