FS-1000/1000+
1-5
(4) Power requirements
(5) Environmental requirements
Item FS-1000 FS-1000+
Voltage/current US/Canada:
Europe/Asia:
Watts Normal operation:
Standby (Ready):
Sleeping:
120 V AC ±10 %,
60 Hz ±2 %/4.9 A
220 - 240 V AC ±10 %,
50/60 Hz ±2 %/2.6 A
120 V AC model: 569 W
220 - 240 V AC model: 569 W
←
120 V AC model: 5 W
220 - 240 V AC model: 6 W
120 V AC ±10 %,
60 Hz ±2 %/4.4 A
220 - 240 V AC ±10 %,
50/60 Hz ±2 %/2.2 A
120 V AC model: 233 W
220 - 240 V AC model: 506 W
41 W
120 V AC model: 6 W
220 - 240 V AC model: 6 W
Item FS-1000 FS-1000+
Operating temperature and
humidity
Maximum altitude
Noise emission (Excluding
peaks, measured at 1 m from
printer, as per ISO7779)
10 to 32.5 °C (50 to 90.5 °F),
20 to 80 %RH
2,000 m (6,500 feet)
Maximum: 48 dB(A) ,
Standby: 28 dB(A)
←
←
←
