Kyocera FS-1000 Plus [133/163] Repetitive defects gauge

6-28

FS-1000/1000+

Repetitive defects gauge

Use the following measurements for checking repetitive occurrences on the printed page. See the

above section for details.

Figure 6-1-2 Repetitive defects gauge

First occurrence of defect

[63 mm] Developing roller (Process unit)

[25 mm] Upper registration roller

[38 mm] Lower registration roller

[61 mm] Heat roller, Press roller (Fuser unit)

[94 mm] Drum (Process unit)

[50 mm] Transfer roller
