Сервис мануал Страница: 12

Kyocera FS-1000 Plus Сервис мануал онлайн [12/163] 134925

1-8

FS-1000/1000+

Label on the scanner unit

(Inside the printer)

Label on the left cover rear side

Laser radiation warning

WARNING Use of controls or adjustments or performance of procedures other than those

specified herein may result in hazardous radiation exposure.

Figure 1-3-1 Laser caution label
