B-6
FS-1000/1000+
Example Meaning Description
8 F00/
9 N00/
0 RS2
! /AF.H
@ G
# /0104
$ /0026
% /1061
^ /0811
& / 0/ 0/ 0/
* /000000
( /030303
) SPD
⁄ 4044404480806E80
¤ SN:
Operaor panel lock (Shown only
during locking)
NVRAM error (Shown only if
error has occurred)
Serial interface mode (Shown
only optional serial interface
board IB-10E is installed)
Average print coverage (total)
Average print coverage (most
recent 20 pages)
Top margin
Left margin
Page length
Page width
Left margin offset for paper
source (MP tray/Printer’s
cassette/Optional paper feeder’s
cassette)
Paper type setting
Print density setting
DRAM SPD (slot 1)
Engine parameter information
Serial number for the printer
01= Partially locked
02= Fully locked
01= ID error, 02= Version error,
03= Checksum error,
04= NVRAM error
RS2= RS-232C, RS4= RS422A
Two digits for integer part; one
digit for decimal; unit is in percent
B= Level 1 (Less than 0.5 %)
C= Level 2 (0.6 to 1.0 %)
D= Level 3 (1.1 to 2.0 %)
E= Level 4 (2.1 to 3.0 %)
F= Level 5 (3.1 to 4.0 %)
G= Level 6 (4.1 to 5.0 %)
H= Level 7 (5.1 to 10.0 %)
I= Level 8 (More than 10.0 %)
Inches+
1
/
100
inches (FRPO L1/L2)
Inches+
1
/
100
inches (FRPO L1/L2)
Inches+
1
/
100
inches (FRPO L1/L2)
Inches+
1
/
100
inches (FRPO L1/L2)
in
1
/
600
inch
Paper type for trays 0, 1, and 2
Print density for trays 0, 1, and 2
Hexadecimal, 8 bytes (16 digits)
-
