LEDS

LED stands for Light-Emitting Diode. The DRS-200 has the following LEDs as

described below:

♦

LED LED Activity

Power Green Power ON

ON On line

Link Indicator

OFF Off line

WLAN

Active Indicator Sparkling Data transmission

ON On line

Link Indicator

OFF Off line

Local

Network

Active Indicator Sparkling Data transmission
