Getting Started

With its default settings, the DRS-200, when activated, will connect with

other D-Link Express Wireless network products, right out of the box.

Please refer to the following

sections of this manual for

additional information about

setting up a network:

Setup Authentication in client

–

learn how to setup authentication

in client, then can connection

Wireless Access Point to Interne

Using the Configuration

Menu - learn the settings for

the DRS-200, using the

web-based

interface.

Application - 1

Application - 2
