Package Contents

Contents of Package:

■ D-link DRS-200 Radius Server

■ Power Adapter – 5V DC

■ Ethernet (CAT5-UTP/Straight-Through) Cable

■ Manual on CD

■ Quick Installation Guide

Note: Using a power supply with a different voltage rating than the one included with the

DRS-200 will cause damage and void the warranty for this product.

If any of the above items are missing, please contact your reseller.

System Requirements For Configuration:

■ Ethernet-Based Cable or DSL Modem

■ Computer with Windows, Macintosh, or Linux-based

operating system with an installed Ethernet adapter

■ Internet Explorer version 6.x or Netscape Navigator

version 6.x and above, with JavaScript enabled
