Connections
Note: System log and Radius log won't be saved if you don't have CF card in your
DRS-200, and all these log files will be lost after power off. An 8MB CF card could be
used to save at about 200 thousand records of log data in average.(This number may
vary depends on the length of each record) and 100 records each of client data and
user’s authentication data. The DRS-200 has the following CF card as described below:
CF card
capacity
Client data
entry
User’s authentication data
entry
System log and Radius log data
entry
8MB 100 100 200 thousand
16MB 100 100 400 thousand
32MB 100 100 800 thousand
Receptor for
the Power
Adapter..
Pressing the Reset
Button restores the
DRS-200 to its original
factory default settings.
WAN PORT This is
for the connection of
an Ethernet cable to
the Hub or Switch
CF Card Socket All syslog and user’s
authentication data can be saved in a
CF Card. While using DRS-200, if you
want to record syslog and user’s
authentication data then save it, you
could plug the CF Card in this Socket
.
Local Network Port This is
a connection for Ethernet
cable to Ethernet enabled
computers. it, you could plug
the CF Card in this Socket
.
