Appendix B - Ethernet Technology DES-1210 Metro Ethernet Managed Switch User Manual
116
- DEM-310GT (1000BASE-LX, 10km)
- DEM-311GT (1000BASE-SX, 550m)
- DEM-314GT (1000BASE-LH, 50km)
- DEM-315GT (1000BASE-ZX, 80km)
- DEM-312GT2 (1000BASE-SX, 2km)
- DEM-210 (100BASE-FX, 15km)
- DEM-211 (100BASE-FX, 2km)
2 combo SFP and 2 individual SFP ports supporting WDM Transceivers:
- DEM-330T (1000Base-BX,TX-1550/RX-1310nm, 10km)
- DEM-330R (1000Base-BX,TX-1310/RX-1550nm, 10km)
- DEM-331T (1000Base-BX,TX-1550/RX-1310nm, 40km)
- DEM-331R (1000Base-BX,TX-1310/RX-1550nm, 40km)
- DEM-220T (100Base-BX, TX-1550/RX-1310nm, 20km)
- DEM-220R (100Base-BX, TX-1310/RX-1550nm, 20km)
Physical & Environment
Internal Power Supply
DES-1210-10/ME: 24W AC Input: 100 – 240 VAC, 50-60 Hz
DES-1210-26/ME: 24W AC Input: 100 – 240 VAC, 50-60 Hz
DES-1210-28/ME: 24W AC Input: 100 – 240 VAC, 50-60 Hz
Operation Temperature
-5~50°C
Storage Temperature
-40~70°C
Operation Humidity
10%~90% RH
Storage Humidity
5%~90% RH
EMI Certifications
FCC, CE,
Safety Certifications
cUL, LVD
