Appendix B - Ethernet Technology DES-1210 Metro Ethernet Managed Switch User Manual
118
DHCP Server Screening: Able to
configure IPv4 and IPv6 addresses for
DHCP server.
SSH: Support v2 and IPv6
SSL: Support v3, IPv4 and IPv6
Smart Binding
- Supports D-Link IMPB
- Supports ARP packet Inspection as default,
ARP and IP packet Inspection as option.
- Supports DHCP Snooping
Dos Attack Prevention
OAM
Cable Diagnostics: Detect and show
cable length and status
802.3ah
- Support 802.3ah link layer remote
loopback and discovery
- 802.3ah D-Link extension: D-link
Undirectional Link Detection (DULD)
Management
Web-based GUI
D-Link proprietary CLI
Telnet Server
SNMP support
DHCP client
DHCP Relay: Support DHCP local relay,
option 82 and 12.
DHCPv6 Relay: Support DHCP local relay
and option 37
SNMP Trap
System Log: Support log server with IPv4
or IPv6 address
RMON v1/v2
Password access control
Password Encryption
Web-based configuration backup /
restoration
Reset, Reboot
