1 Product Introduction DES-1210 Metro Ethernet Managed Switch User Manual
2
2
1 Product Introduction
Switch Description
Front Panel Description
LED Indicators
Rear Panel Description
Side Panel Description
Gigabit Combo Ports
Switch Description
The DES-1210 Metro Ethernet Managed switch is equipped with Copper ports (10/100Mbps) and SFP
ports (100/1000Mbps) that can be used to attach various networking devices to the network like Computers,
Notebooks, Print Servers, Network Attached Storage devices, IP Cameras, VoIP PBX devices, and other
Switches. The Small Form Factor Portable (SFP) combo ports can be used together with fiber-optical
transceivers in order to connect various other networking devices, using a fiber-optic connection, to the
network at Gigabit Ethernet speeds over great distances.
This DES-1210 Metro Ethernet Managed switch provides unsurpassed performance, fault tolerance,
scalability, robust security, standard-based interoperability and impressive technology to future-proof
departmental and enterprise network deployments.
It allows IGMP Snooping and Authentication, QoS, Bandwidth Control, ACL and many security functions. It
can be managed by Web UI, or commands via Telnet.
The DES-1210 Metro Ethernet Managed features the following list of switches:
Switch
Description
DES-1210-10/ME
8 10/100Mbps Copper Ports, 2 Combo 10/100/1000Mbps Copper /
100/1000Mbps SFP Ports, and One RJ-45 Console Port for out-of-band CLI
configuration.
DES-1210-26/ME
24 10/100Mbps Copper Ports, 2 Combo 10/100/1000Mbps Copper /
100/1000Mbps SFP Ports, and One RJ-45 Console Port for out-of-band CLI
configuration.
DES-1210-28/ME
24 10/100Mbps Copper Ports, 2 100/1000Mbps SFP Ports, 2 Combo
10/100/1000Mbps Copper / 100/1000Mbps SFP Ports, and One RJ-45 Console
Port for out-of-band CLI configuration.
These switches have a combination of 1000BASE-T ports and SFP ports that may be used in to uplink
various network devices to the Switch, including PCs, hubs and other switches to provide a gigabit Ethernet
uplink in full-duplex mode. The SFP (Small Form Factor Portable) combo ports are used with fiber-optical
transceiver cabling in order to uplink various other networking devices for a gigabit link that may span great
distances.
Front Panel Description
The front panel of the DES-1210-10/ME switch consists out of the following:
8 10/100Mbps Copper Ports
2 Combo 10/100/1000Mbps Copper / 100/1000Mbps SFP port
One RJ-45 Console Port
LEDs for Power, Console, Link/Act for port 1 to 8, and Link/Act/Speed for port 9 and 10
