3 Getting Started DES-1210 Metro Ethernet Managed Switch User Manual
12
Figure 3.2 –Enter the IP address 10.90.90.90 in the web browser
NOTE: The switch's factory default IP address is
10.90.90.90 with a subnet mask of 255.0.0.0 and
a default gateway of 0.0.0.0.
When the following logon dialog box appears, enter the password and choose the language of the Web-
based Management interface then click OK.
By default, the Username and Password are empty.
Figure 3.3 – Logon Dialog Box
Web-based Management
By clicking the OK button in Logon Dialog Box, you will enter the Web-based Management interface. Please
refer to Chapter 4 Configuration for detailed instructions.
