D-Link DES-1210-10/ME [86/129] Security access authentication control login method lists

4 Configuration DES-1210 Metro Ethernet Managed Switch User Manual

Figure 4.134 – Security > Access Authentication control > Authentication Server

To add an Authentication Server Host:

IP Address: Select IPv4 or IPv6 and enter the IP address.

Protocol: The protocol used by the server host. The user may choose one of the following:

TACACS+ – Enter this parameter if the server host utilizes the TACACS+ protocol.

RADIUS – Enter this parameter if the server host utilizes the RADIUS protocol.

Key: Authentication key to be shared with a configured TACACS+ or RADIUS servers only. Specify an

alphanumeric string up to 254 characters.

Port (1 - 65535): Enter a number between 1 and 65535 to define the virtual port number of the

authentication protocol on a server host. The default port number is 49 for TACACS+ server and 1813 for

RADIUS servers but the user may set a unique port number for higher security.

Timeout (1 - 255): Enter the time in seconds the Switch will wait for the server host to reply to an

authentication request. The default value is 5 seconds.

Retransmit (1 - 255): Enter the value in the retransmit field to change how many times the device will resend

an authentication request when the TACACS server does not respond.

Click Apply to add a new Authentication Server Host.

NOTE: More than one authentication protocol can

be run on the same physical server host.

Security > Access Authentication Control > Login Method Lists

This feature will configure a user-defined or default Login Method List of authentication techniques for users

logging on to the Switch. Successful login using any of these techniques will give the user a "User" privilege

only. To upgrade his or her status to the administrator level, the user must use the Enable Admin window, in

which the user must enter a previously configured password, set by the administrator.

The Switch contains one Method List that is set and cannot be removed, yet can be modified. To delete a

Figure 4.135 – Security > Access Authentication control > Login Method Lists

To define a Login Method List, set the following parameters and click Apply:

Method List Name: Enter a method list name defined by the user of up to 15 characters.

Priority 1, 2, 3, 4: The user may add one, or a combination of up to four of the following authentication

methods to this method list:

none – Adding this parameter will require an authentication to access the Switch.

local – Adding this parameter will require the user to be authenticated using the local user account

database on the Switch.
