1SFC101220C0201
ABB Motor protection and control - short form catalog | 5/67
EK550, EK1000 4-pole contactors
with 1 N.O. + 1 N.C. auxiliary contacts
and 2 N.O. + 1 N.C. auxiliary contacts
A1
A2
A1
A2
315 351
426 46
2
77
8 8
E0747D
BSS550 ... BSS1000
A078
RC-EH
Ordering details (1)
For contactors Auxiliary
contacts
Type Order code Pkg
qty
Weight
(1 pce)
kg
Side-mounted auxiliary contact blocks
EK 1 1 CAL16-11B SK829002-B 1 0.050
1 1 CAL16-11C SK829002-C 1 0.050
1 1 CAL16-11D SK829002-D 1 0.050
1 1 CCL16-11E (2) SK829002-E 1 0.050
Mechanical interlock unit for two horizontal mounted contactors
EK550, EK1000 VH800 SK829070-F 1 6.000
Connecting sets
EK550
BSS550 SK829090-E 1 3.300
EK1000
BSS1000 SK829090-H 1 5.500
Surge suppressors
For contactors Rated control circuit
voltage
Uc
Type Order code Pkg Weight
qty (1 pce)
V AC DC kg
EK550, EK1000
48...110
●
– RC-EH800/110 SK829007-C 1 0.015
EK550, EK1000
24...125 –
●
RC-EH800/110 SK829007-C 1 0.015
EK550, EK1000
220...600
●
– RC-EH800/600 SK829007-D 1 0.015
(1) See "Main accessory fitting details" table.
(2) Mounting of CCL16-11E blocks does not allow an additional second block to be added on top of it.
All DC operated EK contactors are equipped with one CCL16-11E on the right side.
