1SBC101297S0201
4/12 | ABB Motor protection and control - short form catalog
AS09...AS16 and
ASL09...ASL16 3-pole contactors
Main accessories
Main accessory fitting details
Many configurations of accessories are possible depending on whether these are front-mounted or side-mounted.
Contactor
types
Main
poles
Built-in
auxiliary
contacts
Front-mounted accessories Side-mounted accessories
Auxiliary contact blocks Electronic timer Mechanical interlock unit
(between 2 contactors)
1-pole CA3 TEF3 VM3 Surge suppressors
AS09...AS16 3 0 1 0 2 max.
or
1
+
1
+
RV5
or
RC5-1
3 0 0 1
AS09...AS16 3 0 3 2 – – 1
+
RV5
or
RC5-1
ASL09...ASL16 3 0 1 0 2 max.
or
1
+
1
+
RV5
or
RT5
3 0 0 1
ASL09...ASL16 3 0 3 2 – – 1
+
RV5
or
RT5
Overload relays fitting details (1)
Contactor types Thermal overload relays
AS09…AS16 T16 (0.10...16 A)
ASL09…ASL16
The addition of an overload relay on the contactor does not prevent fitting of many other accessories as shown above.
(1) Direct mounting - No kit required.
Contactor and main accessories (other accessories available)
BEY16C-3
BER16C-3
BEA16-3
MS116
VM3
(optional)
VM3
T16
T16
AS
ASL
Contactors
TEF3
CA3
RV5, RC5-1 or RT5
AS
ASL
Contactors
AS
ASL
Contactors
4
Time) Time) Time)
