Voltage code table
The below tables indicate the available coil voltages and corresponding digits for order codes. When placing an order, please
give either type or order code. Select a standard contactor from ordering detail pages. Change the coil voltage code in the
type or in the order code according to the table below. Example: for contactor AS09-30-10 and coil 42 V 50/60 Hz, type is
AS09-30-10-21 and order code is 1SBL101001R2110.
Auxiliary contacts
N.O. N.C.
N.O. N.C.
Number contacts
N.O. N.C.
Main contacts
Type
Type
Order code
Order code
Contactor type
Contactor type
AS16 - 30 - 10 - 26
NS 40 E - 26
AS AC operated
ASL DC operated
NS AC operated
NSL DC operated
AC coil code
AC coil code
50 Hz 60 Hz
20 24V 24V
21 42V 42V
22 48V 48V
23 110V 110V
24 115V 115V
16 – 120V
25 220V 220V
26 230V 230V
27 240V 240V
17 – 277V
13 380V –
28 400V 400V
29 415V 415V
50 Hz 60 Hz
20 24V 24V
21 42V 42V
22 48V 48V
23 110V 110V
24 115V 115V
16 – 120V
25 220V 220V
26 230V 230V
27 240V 240V
17 – 277V
13 380V –
28 400V 400V
29 415V 415V
1SBL121001R 26 10
1SBH101001R 26 40
DC coil code
80 12 V
81 24 V
83 48 V
84 60 V
86 110 V
87 125 V
88 220 V
89 240 V
DC coil code
80 12 V
81 24 V
83 48 V
84 60 V
86 110 V
87 125 V
88 220 V
89 240 V
