ABB Motor protection and control - short form catalog | 3/1
B mini contactors
K mini contactor relays
3
Overview 3/2
3-pole mini contactors
B6, B7 AC operated 3/4
BC6, BC7, B7D DC operated 3/5
3-pole mini reversing contactors
VB6, VB7 AC operated 3/6
VBC6, VBC7 DC operated 3/7
3-pole interface mini contactors
BC6, BC7 DC operated 3/8
3-pole contactors - large coil voltage range
TBC7 DC operated 3/9
4-pole mini contactors
B6, B7 AC operated 3/10
BC6, B7D DC operated 3/11
4-pole contactors - large coil voltage range
TBC7 DC operated 3/12
4-pole mini contactor relays
K6 AC operated 3/13
KC6 DC operated 3/14
4-pole interface mini contactor relays
KC6 DC operated 3/15
4-pole mini contactor relays - large coil voltage range
TKC6 DC operated 3/16
Accessories 3/17
For direct product details information, use product type or order code, ex:
www.abb.com/productdetails/AF09-30-10-13 or www.abb.com/productdetails/1SBL137001R1310
