- 103 - BIOS Setup

Parameter

Description

Wait BMC Ready

POST wait BMC ready and reboot system.

Options available: Disabled, 2 minutes, 4 minutes, 6 minutes.

Default setting is 2 minutes.

System Event Log

Press[Enter]tocongureadvanceditems.

View FRU

Information

Press [Enter] to view the FRU information.

BMC network

conguration

Press[Enter]tocongureadvanceditems.

IPv6 BMC Network

Conguration

Press[Enter]tocongureadvanceditems.
