Gigabyte MZ01-CE0 (rev. 2.x) [95/137] 3 6 ntb common options

- 95 - BIOS Setup

2-3-6 NTB Common Options

Parameter

Description

NTB Common Options

NTB Enable

Options available: Auto/Enabled. Default setting is Auto.
