Gigabyte MZ01-CE0 (rev. 2.x) [26/137] Led_bmc bmc firmware readiness led

Hardware Installation - 26 -

CPU

DIMM_P0_G0

DIMM_P0_H0

DIMM_P0_E0

DIMM_P0_F0

DIMM_P0_B0

DIMM_P0_A0

DIMM_P0_D0

DIMM_P0_C0

20) LED_BMC (BMC Firmware Readiness LED)

State Description

On BMCrmwareisinitial

Blink BMCrmwareisready

Off AC loss

LED_BMC
