Gigabyte MZ01-CE0 (rev. 2.x) [54/137] 2 14 iscsi configuration

BIOS Setup - 54 -

2-2-14 iSCSI Conguration

Parameter

Description

iSCSI Initiator Name

Press [Enter] and name iSCSI Initiator. Only IQN format is accecpted.

Range: from 4 to 223.

Add an Attempt

Press[Enter]tocongureadvanceditems.

Delete Attempts

Press[Enter]tocongureadvanceditems.

Change Attempt Order

Press[Enter]tocongureadvanceditems.
