Gigabyte MZ01-CE0 (rev. 2.x) [34/137] 2 1 trusted computing

BIOS Setup - 34 -

2-2-1 Trusted Computing

Parameter

Description

Conguration

Security Device Support

Enable/Disable BIOS support for security device. OS will not show

security device. TCG EFI protocol and INT1A interface will not be

available.

Options available: Enable/Disable. Default setting is Enable.
