BIOS Setup - 116 -

2-10 ABL POST Codes

2-10-1 StartProcessorTestPoints

Entry used for range testing for @b Processor related TPs 0xE000

2-10-2 Memory test points

Memory structure initialization (Public interface) 0xE001

SPD Data processing (Public interface) 0xE002

Memoryconguration(Publicinterface)Phase1 0xE003

DRAM initialization 0xE004

ProcMemSPDChecking 0xE005

ProcMemModeChecking 0xE006

SpeedandTCLconguration 0xE007

ProcMemSpdTiming 0xE008

ProcMemDramMapping 0xE009

ProcMemPlatformSpecicCong 0xE00A

ProcMemPhyCompensation 0xE00B

ProcMemStartDcts 0xE00C

ProcMemBeforeDramInit (Public interface) 0xE00D

ProcMemPhyFenceTraining 0xE00E

ProcMemSynchronizeDcts 0xE00F

ProcMemSystemMemoryMapping 0xE010

ProcMemMtrrConguration 0xE011

ProcMemDramTraining 0xE012

ProcMemBeforeAnyTraining(Public interface) 0xE013

2-10-3 PMU Test Points

ABL Mem - PMU - Before PMU Firmware load 0xE014

ABL Mem - PMU - After PMU Firmware load 0xE015

ABL Mem - PMU Populate SRAM Timing 0xE016

ABLMem-PMUPopulateSRAMCong 0xE017

ABL Mem - PMU Write SRAM Msg Block 0xE018

ABL Mem - Wait for Phy Cal Complete 0xE019

ABL Mem - Phy Cal Complete 0xE01A

ABL Mem - PMU Start 0xE01B

ABL Mem - PMU Started 0xE01C

ABL Mem - PMU Waiting for Complete 0xE01D

ABL Mem - PMU Stage Dec Init 0xE01E

ABL Mem - PMU Stage Training Wr Lvl 0xE01F

ABL Mem - PMU Stage Training Rx En 0xE020

ABL Mem - PMU Stage Training Rd Dqs 0xE021

ABL Mem - PMU Stage Traning Rd 2D 0xE022
