- 73 - BIOS Setup

2-3-3 UMC Common Options

Parameter Description

UMC Common Options

DDR4 Common Options Press[Enter]forcongurationofadvanceditems.

DRAM Memory Mapping Press[Enter]forcongurationofadvanceditems.

NVDIMM Press[Enter]forcongurationofadvanceditems.

Memory MBIST Press[Enter]forcongurationofadvanceditems.
