Gigabyte MZ01-CE0 (rev. 2.x) [77/137] 3 3 1 3 data bus configuration

- 77 - BIOS Setup

2-3-3-1-3 Data Bus Conguration

Parameter Description

DataBusConguration

DataBusCongurationUser

Controls

SpeciesthemodefordrivestrengthtoAutoorManual.

Options available: Auto/Manual. Default setting is Auto.
