Gigabyte MZ01-CE0 (rev. 2.x) [137/137] 12 bios post beep code ami standard

- 137 - BIOS Setup

2-12 BIOS POST Beep code (AMI standard)

2-12-1 PEI Beep Codes

# of Beeps Description

Memory not Installed.

Memory was installed twice (InstallPeiMemory routine in PEI Core called

twice)

Recovery started

3 DXEIPL was not found

3 DXE Core Firmware Volume was not found

4 Recovery failed

S3 Resume failed

Reset PPI is not available

2-12-2 DXE Beep Codes

# of Beeps Description

1 Invalid password

4 Some of the Architectural Protocols are not available

5 No Console Output Devices are found

5 No Console Input Devices are found

6 Flash update is failed

7 Reset protocol is not available

8 Platform PCI resource requirements cannot be met
