- 93 - BIOS Setup

2-3-5-1 AC Power Loss Options

Parameter

Description

AC Power Loss Options

AC Loss Control

Selects the AC Loss Control Method.

Options available: Power Off, Power On, Last State.

Default setting is Last State.
