- 43 - BIOS Setup

Parameter

Description

Serial Port for Out-of-Band

EMS Console Redirection

Settings(continued)



Flow Control

– Flowcontrolcanpreventdatalossfrombufferoverow.When

sending data, if the receiving buffers are full, a 'stop' signal can

besenttostopthedataow.Oncethebuffersareempty,a'start'

signalcanbesenttore-starttheow.Hardwareowcontroluses

two wires to send start/stop signals.

– Options available: None, Hardware RTS/CTS, Software Xon/Xoff.

Default setting is None.
