BIOS Setup - 56 -
Parameter
Description
NICConguration
Press[Enter]tocongureadvanceditems.
Link Speed
– Allowsforautomaticlinkspeedadjustment.
– Options available: Auto Negotiated, 10 Mbps Half, 10 Mbps Full,
100 Mbps Half, 100 Mbps Full. Default setting is Auto Negotiated.
Wake On LAN
– EnablespoweronofthesystemviaLAN.Notethatconguring
Wake on LAN in the operating system does not change the value of
this setting, but does override the behavior of Wake on LAN in OS
controlled power states.
– Options available: Enabled/Disabled. Default setting is Enabled.
Blink LEDs
IdentiesthephysicalnetworkportbyblinkingtheassociatedLED.
Pressthenumerickeystoadjustdesiredvalues.
UEFI Driver
DisplaysthetechnicalspecicationsfortheNetworkInterfaceController.
Adapter PBA
DisplaysthetechnicalspecicationsfortheNetworkInterfaceController.
Device Name
DisplaysthetechnicalspecicationsfortheNetworkInterfaceController.
Chip Type
DisplaysthetechnicalspecicationsfortheNetworkInterfaceController.
PCI Device ID
DisplaysthetechnicalspecicationsfortheNetworkInterfaceController.
PCI Address
DisplaysthetechnicalspecicationsfortheNetworkInterfaceController.
Link Status
DisplaysthetechnicalspecicationsfortheNetworkInterfaceController.
MAC Address
DisplaysthetechnicalspecicationsfortheNetworkInterfaceController.
Virtual MAC Address
DisplaysthetechnicalspecicationsfortheNetworkInterfaceController.
