- 79 - BIOS Setup

Parameter Description

DisableMemoryErrorInjection Options available: False/True. Default setting is True.

ECCConguration

Press[Enter]tocongureadvanceditems.



DRAM ECC Symbol Size

– CongurestheDRAMECCSymbolSize.

– Options available: Auto, x4, x8, x16. Default setting is Auto.



DRAM ECC Enable

– Enable/Disable DRAM ECC. When set to Auto, it will set ECC

to enable.

– Options available: Auto, Enabled, Disabled. Default setting is

Auto.



DRAM UECC Retry

– Enable/Disable DRAM UECC Retry.

– Options available: Auto, Enabled, Disabled. Default setting is

Auto.
