- 89 - BIOS Setup

Parameter

Description

DF Cstates

Enable/Disable DF C-states.

Options available: Auto, Enabled, Disabled. Default setting is Auto.

CPPC

Enable/Disable the CPPC feature.

Options available: Auto, Enabled, Disabled. Default setting is Auto.

BoostFmaxEn Options available: Auto/Enabled. Default setting is Auto.
