Special Control Si34-803_B
147 Function
3.5 Pump down Residual Operation
3.5.1 Pump down Residual Operation in Cooling Operation
If the liquid refrigerant stays in the evaporator at the startup of a compressor, this liquid refrigerant enters the
compressor, thus resulting in diluted oil in the compressor and then degraded lubrication performance.
Consequently, in order to recover the refrigerant in the evaporator while the compressor stops, the pump down residual
operation is conducted.
* Actuators are based on RXYQ14~18P(A).
3.5.2 Pump down Residual Operation in Heating Operation
* Actuators are based on RXYQ14~18P(A).
Actuator Master unit operation Slave unit operation
Compressor 124 Hz + OFF + OFF OFF
Outdoor unit fan Fan control OFF
Four way valve OFF OFF
Main electronic expansion valve (EV1) 480 pls 0 pls
Subcooling electronic expansion valve
(EV2)
0 pls 0 pls
Hot gas bypass valve (SVP) OFF OFF
Accumulator oil return valve (SVO) ON ON
Ending conditions
• 5 min.
• Master Unit Pe<0.49 MPa
• Master Unit Td>110°C
• Master Unit Pc>2.94 MPa
or
Actuator Master unit operation Slave unit operation
Compressor 124 Hz + OFF + OFF OFF
Outdoor unit fan STEP 7 STEP 4
Four way valve ON ON
Main electronic expansion valve (EV1) 0 pls 0 pls
Subcooling electronic expansion valve
(EV2)
0 pls 0 pls
Hot gas bypass valve (SVP) OFF OFF
Accumulator oil return valve (SVO) ON ON
Ending conditions
• 3 min.
• Master Unit Pe<0.25 MPa
• Master Unit Td>110°C
• Master Unit Pc>2.94 MPa
or
