Troubleshooting by Remote Controller Si34-803_B
251 Troubleshooting
2.4 Malfunction Codes and Description
k: ON h: OFF l: Blink
Malfunction
code
Operation
lamp
Malfunction contents Page
Referred
Indoor Unit A0 l Error of external protection device 257
A1 l PCB defect, E
2
PROM defect 258
A3 l Malfunction of drain level control system (S1L) 259
A6 l Fan motor (M1F) lock, overload 261,
262
A7 k Malfunction of swing flap motor (M1S) 265
A8 l Abnormal power supply voltage 267
A9 l Malfunction of electronic expansion valve coil (Y1E) 268
AF k Drain level above limit 270
AH k Malfunction of air filter maintenance —
AJ l Malfunction of capacity Determination Device 271
C1 l Failure of transmission (between indoor unit PCB and fan PCB) 272
C4 l Malfunction of thermistor (R2T) for heat exchange (loose connection,
disconnection, short circuit, failure)
274
C5 l Malfunction of thermistor (R3T) for gas pipe (loose connection,
disconnection, short circuit, failure)
275
C6 l Failure of combination (between indoor unit PCB and fan PCB) 276
C9 l Malfunction of thermistor (R1T) for suction air (loose connection,
disconnection, short circuit, failure)
277
CC k Malfunction of humidity sensor system 278
CJ k Malfunction of thermostat sensor in remote controller 279
Outdoor Unit E1 l PCB defect 280
E3 l Actuation of high pressure switch 281
E4 l Actuation of low pressure sensor 283
E5 l Inverter compressor motor lock 285
E6 l STD compressor motor overcurrent/lock 287
E7 l Malfunction of outdoor unit fan motor 288
E9 l Malfunction of electronic expansion valve coil (Y1E, Y2E) 291
F3 l Abnormal discharge pipe temperature 293
F6 l Refrigerant overcharged 294
H7 l Abnormal outdoor fan motor signal 295
H9 l Malfunction of thermistor (R1T) for outdoor air (loose connection,
disconnection, short circuit, failure)
296
J2 l Current sensor malfunction 297
J3 l Malfunction of discharge pipe thermistor (R3, R31~33T) (loose connection,
disconnection, short circuit, failure)
298
J5 l Malfunction of thermistor (R2T, R7T) for suction pipe (loose connection,
disconnection, short circuit, failure)
299
J6 l Malfunction of thermistor (R4T) for outdoor unit heat exchanger (loose
connection, disconnection, short circuit, failure)
300
J7 l Malfunction of liquid pipe thermistor (R6T) 301
J9 l Malfunction of subcooling heat exchanger gas pipe thermistor (R5T) 302
JA l Malfunction of high pressure sensor 303
JC l Malfunction of low pressure sensor 304
L0 l Inverter system error —
L4 l Malfunction of inverter radiating fin temperature rise 305
L5 l Inverter compressor abnormal 307
L8 l Inverter current abnormal 309
