Field Setting Si34-803_B
203 Test Operation
In the Case of FXUQ71~125
(14) Airflow Direction Setting
Set the airflow direction of indoor units as given in the table below. (Set when optional air outlet
blocking pad has been installed.) The second code No. is factory setting to “01.”
(15) Operation of Downward Flow Flap: Yes/No
Only the model FXKQ has the function.
When only the front-flow is used, sets yes/no of the swing flap operation of down-flow.
(16) Setting of Airflow Direction Adjustment Range
Make the following airflow direction setting according to the respective purpose.
∗
Some indoor unit models are not equipped with draft prevention (upward) function.
(17) Setting of the Static Pressure Selection
In the Case of FXDQ20~32PB, FXDQ40~63NB
Mode
No.
First
Code
No.
Second
Code
No.
Setting
Ceiling Height
4-way Outlets 3-way Outlets 2-way Outlets
13 (23) 0
01 Standard (N) Lower than 2.7 m Lower than 3.0 m Lower than 3.5 m
02 High Ceiling (H) Lower than 3.0 m Lower than 3.5 m Lower than 3.8 m
03 Higher Ceiling (S) Lower than 3.5 m Lower than 3.8 m —
Mode No. First Code No.
Second Code
No.
Setting
13 (23) 1
01 F : 4-direction airflow
02 T : 3-direction airflow
03 W : 2-direction airflow
Mode No. First Code No. Second Code No. Setting
13 (23) 3
01 Down-flow operation: Yes
02 Down-flow operation: No
Mode No. First Code No. Second Code No. Setting
13 (23) 4
01
Upward (Draft
prevention)
02 Standard
03
Downward (Ceiling
soiling prevention)
Model No. First Code No. Second Code No. External static pressure
13 (23) 5
01 Standard (10Pa)
02
High static pressure (30Pa)
