Si34-803_B List of Electrical and Functional Parts
Appendix 414
Parts Name
Symbol
Model
Remark
FXMQ200MAVE FXMQ250MAVE
Remote
Controller
Wired Remote
Controller
BRC1D61 / BRC1E61
Option
Wireless Remote
Controller
BRC4C62
Motors
Fan Motor M1F
AC 220~240V 50Hz
1
φ380W×2
Capacitor for Fan Motor C1R 10
µ F 400V 12µ F 400V
Thermistors
Thermistor (Suction Air)
R1T
ST8601A-13
φ4 L630
Thermistor (for Heat
Exchanger High Temp.)
R3T
ST8605A-5
φ8 L1000
Thermistor (Heat
Exchanger)
R2T
ST8602A-6
φ6 L1250
Others
Float switch S1L FS-0211
Fuse F1U 250V 5A
φ5.2
Transformer T1R TR22H21R8
Parts Name Symbol
Model
Remark
FXHQ
32MAVE
FXHQ
63MAVE
FXHQ
100MAVE
Remote
Controller
Wired Remote
Controller
BRC1D61 / BRC1E61 Option
Wireless Controller BRC7E63W
Motors
Fan Motor M1F
AC 220~240V/220V 50Hz/60Hz
1
φ63W 1φ130W
Thermal protector 130°C : OFF 80°C : ON
Capacitor for Fan Motor
C1R 3.0
µF-400V
9.0µF-400V
Swing Motor M1S
MT8-L[3P058751-1]
AC200~240V
Thermistors
Thermistor (Suction Air)
R1T
ST8601A-1
φ4 L250
20k
Ω (25°C)
Thermistor (for Heat
Exchanger High Temp.)
R3T
ST8605-6
φ8 L = 1250
20kΩ (25°C)
ST8605-6 φ8 L
= 1250
20kΩ (25°C)
Thermistor (Heat
Exchanger)
R2T
ST8602A-6 φ6 L = 1250
20kΩ (25°C)
ST8602A-6 φ6 L
= 1250
20kΩ (25°C)
Others
Fuse F1U 250V 5A
φ5.2
Transformer T1R TR22H21R8
