Si34-803_B Specifications
Specifications 66
Ceiling Mounted Duct Type
Note:
★
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5 m, level
difference : 0 m.
★
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5 m, level
difference : 0 m.
★
3 Indoor temp. : 20°CDB / outdoor temp. : 7°CDB, 6°CWB / Equivalent piping length : 7.5 m, level difference :
0 m.
★
4 External static pressure is changeable in 7 (FXMQ20PVE / FXMQ25PVE / FXMQ32PVE),
13 (FXMQ40PVE), 14 (FXMQ50PVE / FXMQ63PVE / FXMQ80PVE / FXMQ100PVE / FXMQ125PVE),
10 (FXMQ140PVE) stages within the ( ) range by remote controller.
★
5 Air filter is not standard accessory, but please mount it in the duct system of the suction side. Select its
colourimetric method (gravity method) 50% or more.
6 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
★
7 Anechoic chamber conversion value, measured at a point 1.5 m downward from the unit center. During
actual operation, these values are normally somewhat higher as a result of ambient conditions.
Model FXMQ100PVE FXMQ125PVE FXMQ140PVE
Power supply 1 phase 50Hz 220-240V / 60Hz 220V 1 phase 50Hz 220-240V / 60Hz 220V 1 phase 50Hz 220-240V / 60Hz 220V
★
1 *6 Cooling capacity (19.5°CWB)
kcal/h 10,000 12,500 14,300
Btu/h 39,600 49,500 57,000
kW 11.6 14.5 16.7
★
2 *6 Cooling capacity (19.0°CWB) kW 11.2 14.0 16.0
★
3 *6 Heating capacity
kcal/h 10,800 13,800 15,500
Btu/h 42,700 54,600 61,400
kW 12.5 16.0 18.0
Casing Galvanized steel plate Galvanized steel plate Galvanized steel plate
Dimensions: (H×W×D) mm 300×1,400×700 300×1,400×700 300×1,400×700
Coil (Cross
fin coil)
Rows×Stages×Fin pitch mm 3×16×1.75 3×16×1.75 3×16×1.5
Face area m² 0.383 0.383 0.383
Fan
Model — — —
Type Sirocco fan Sirocco fan Sirocco fan
Motor output × Number
of units
W 350×1 350×1 350×1
Airflow rate (HH/H/L)
m³/min 32/27/23 39/33/28 46/39/32
cfm 1,130/953/812 1,377/1,165/988 1,624/1,377/1,130
External static
pressure
Pa Standard 100 (200-50
★
4) Standard 100 (200-50
★
4) Standard 100 (140-50
★
4)
Drive Direct drive Direct drive Direct drive
Temperature control
Microprocessor thermostat for cooling
and heating
Microprocessor thermostat for cooling
and heating
Microprocessor thermostat for cooling
and heating
Air filter
★
5
★
5
★
5
Piping
connections
Liquid pipes mm
φ
9.5 (Flare connection)
φ
9.5 (Flare connection)
φ
9.5 (Flare connection)
Gas pipes mm
φ
15.9 (Flare connection)
φ
15.9 (Flare connection)
φ
15.9 (Flare connection)
Drain pipe mm
VP25
External dia. 32
Internal dia. 25
VP25
External dia. 32
Internal dia. 25
VP25
External dia. 32
Internal dia. 25
Mass (Weight) kg 46 46 47
★
7 Sound level (HH/H/L) dBA
220V 43/41/39 44/42/40 46/45/43
240V 43/41/39 44/42/40 46/45/43
Safety devices
Fuse.
Fan driver overload protector.
Fuse.
Fan driver overload protector.
Fuse.
Fan driver overload protector.
Refrigerant control Electronic expansion valve Electronic expansion valve Electronic expansion valve
Connectable outdoor unit R-410A P(A) series R-410A P(A) series R-410A P(A) series
Standard accessories
Operation manual. Installation manual.
Drain hose. Sealing pads. Clamps.
Washers. Screws. Insulation for fitting.
Clamp metal. Air discharge flange. Air
suction flange.
Operation manual. Installation manual.
Drain hose. Sealing pads. Clamps.
Washers. Screws. Insulation for fitting.
Clamp metal. Air discharge flange. Air
suction flange.
Operation manual. Installation manual.
Drain hose. Sealing pads. Clamps.
Washers. Screws. Insulation for fitting.
Clamp metal. Air discharge flange. Air
suction flange.
Drawing No. C : 3D060388E
() () ()
Conversion formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
