Si34-803_B Specifications
Specifications 46
Heat Pump 60Hz High COP Series (Energy Saving Series) <RXYQ-P(A)H>
Notes:
★
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
★
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
★
3 Indoor temp. : 20°CDB / outdoor temp. : 7°CDB, 6°CWB / Equivalent piping length : 7.5m, level difference :
0m.
4 The units with anti-corrosion treatment will be available as standard. Please specify the suffix “E” as
RXYQ16PAHYLE.
Model Name (Combination Unit)
YL(E)
RXYQ16PAHYL(E) RXYQ18PAHYL(E)
Model Name (Independent Unit) RXYQ8PAYL(E)+RXYQ8PAYL(E) RXYQ8PAYL(E)+RXYQ10PAYL(E)
Model Name (Combination Unit)
TL(E)
RXYQ16PHTL(E) RXYQ18PHTL(E)
Model Name (Independent Unit) RXYQ8PTL(E)+RXYQ8PTL(E) RXYQ8PTL(E)+RXYQ10PTL(E)
★
1 Cooling Capacity (19.5°CWB)
kcal / h 38,800 43,600
Btu / h 154,000 173,000
kW 45.1 50.7
★
2 Cooling Capacity (19.0°CWB) kW 44.8 50.4
★
3 Heating Capacity
kcal / h 43,000 48,600
Btu / h 171,000 193,000
kW 50.0 56.5
Casing Color
Without(E)
Ivory White (5Y7.5/1) Ivory White (5Y7.5/1)
With(E) Light Camel (2.5Y6.5/1.5) Light Camel (2.5Y6.5/1.5)
Dimensions: (H×W×D) mm (1680×930×765)+(1680×930×765) (1680×930×765)+(1680×930×765)
Heat Exchanger Cross Fin Coil Cross Fin Coil
Comp.
Type Hermetically Sealed Scroll Type Hermetically Sealed Scroll Type
Piston
Displacement
m³/h
YL(E) (16.90)+(16.90) (16.90)+(13.34+12.52)
TL(E) (16.90)+(16.90) (16.90)+(13.34+12.52)
Number of
Revolutions
r.p.m
YL(E) (7980)+(7980) (7980)+(6300, 3450)
TL(E) (7980)+(7980) (7980)+(6300, 3450)
Motor Output×Number
of Units
kW (4.5×1)+(4.5×1) (4.5×1)+((1.4+4.5)×1)
Starting Method Soft start Soft start
Fan
Type Propeller Fan Propeller Fan
Motor Output kW (0.75×1)+(0.75×1) (0.75×1)+(0.75×1)
Airflow Rate m³/min 180+180 180+185
Drive Direct Drive Direct Drive
Connecting
Pipes
Liquid Pipe mm
φ
12.7 (Brazing Connection)
φ
15.9 (Brazing Connection)
Gas Pipe mm
φ
28.6 (Brazing Connection)
φ
28.6 (Brazing Connection)
Product Mass (Machine weight) kg 205+205 205+249
Safety Devices
High Pressure Switch, Fan Driver Overload Protector,
Overcurrent Relay, Inverter Overload Protector
High Pressure Switch, Fan Driver Overload Protector,
Overcurrent Relay, Inverter Overload Protector
Defrost Method Deicer Deicer
Capacity Control % 10~100 8~100
Refrigerant
Refrigerant Name R-410A R-410A
Charge kg 7.2+7.2 7.2+7.9
Control Electronic Expansion Valve Electronic Expansion Valve
Refrigerator Oil Refer to the nameplate of compressor Refer to the nameplate of compressor
Standard Accessories
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Drawing No.
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
