Field Setting Si34-803_B
197 Test Operation
3.1.4 Setting Contents and Code No.
Notes : 1. Settings are made simultaneously for the entire group, however, if you select the mode No.
inside parentheses, you can also set by each individual unit. Setting changes however
cannot be checked except in the individual mode for those in parentheses.
2. The mode numbers inside parentheses cannot be used by wireless remote controllers, so
they cannot be set individually. Setting changes also cannot be checked.
3. Marked are factory setting.
4. Do not make settings other than those described above. Nothing is displayed for functions
the indoor unit is not equipped with.
5. “88” may be displayed to indicate the remote controller is resetting when returning to the
normal mode.
6. If the setting mode to “Equipped”, heat reclaim ventilation fan conducts the fan residual
operation by linking to indoor unit.
7. • The FXMQ50·63·80·100·125PVE cannot be set to 30Pa.
• The FXMQ40PVE cannot be set to 180 or 200Pa.
Mode
No.
Note 2
First
Code
No.
Setting Contents
Second Code No.(Note 3)
Details
No.
01 02 03 04
10
(20)
0
Filter contamination heavy/light
(Setting for display time to clean
air filter)
(Sets display time to clean air filter
to half when there is heavy filter
contamination.)
Ultra
long life
filter
Light
Approx.
10,000
hrs.
Heavy
Approx.
5,000
hrs.
——
(1)
Long life
filter
Approx.
2,500
hrs.
Approx.
1,250
hrs.
Standar
d
filter
Approx.
200 hrs.
Approx.
100 hrs.
1 Long life filter type Long life filter
Ultra long life
filter
——(2)
2 Thermostat sensor in remote controller
Remote controller/
indoor unit
Indoor unit
Remote
controller
—(3)
3
Display time to clean air filter calculation (Set
when filter sign is not to be displayed.)
Display No display — — (4)
11
(21)
7 Airflow adjustment OFF
Completion of
airflow
adjustment
Start of airflow
adjustment
—(5)
12
(22)
0
Optional accessories output selection (field
selection of output for adaptor for wiring)
Indoor unit turned
ON by thermostat
—
Operation
output
Malfunction
output
(6)
1
ON/OFF input from outside (Set when ON/
OFF is to be controlled from outside.)
Forced OFF ON/OFF control
External protection
device input
—(7)
2
Thermostat differential changeover
(Set when remote sensor is to be used.)
1°C 0.5°C — — (8)
3 OFF by thermostat fan speed LL Preset airflow — — (9)
4
Automatic mode differential (automatic
temperature differential setting for VRV
system heat recovery series cool/heat)
01:0 02:1 03:2 04:3 05:4 06:5 07:6 08:7 (10)
5 Power failure automatic reset Not equipped Equipped — — (11)
6 Airflow when cooling thermostat is OFF LL airflow Preset airflow — — (12)
13
(23)
0
High air outlet velocity
(Set when installed in place with ceiling
higher than 2.7 m.)
N H S — (13)
1
Selection of airflow direction (Set when a
blocking pad kit has been installed.)
F (4 directions) T (3 directions) W (2 directions) — (14)
3
Airflow direction adjustment (Set at
installation of decoration panel.)
Equipped Not equipped — — (15)
4 Field set airflow position setting Draft prevention Standard
Ceiling Soiling
prevention
— (16)
5 Setting of the static pressure selection Standard
High static
pressure
— — (17)
6 External static pressure settings
01:30 02:50 03:60 04:70 05:80 06:90 07:100 08:110
(18)
09:120 10:130 11:140 12:150 13:160 14:180 15:200 *7
15
(25)
2
Direct duct connection
(when the indoor unit and heat reclaim
ventilation unit are connected by duct
directly.)
∗
Note 6
Not equipped Equipped — — (19)
5
Field set selection for individual ventilation
setting by remote controller
—
Individual
operation
— — (20)
