Si34-803_B Troubleshooting by Remote Controller
Troubleshooting 250
3. Indoor Status Display
2/2
1.Unit No. Select the Unit No. you want to check.
2.Th1 Suction air thermistor
3. Th2 Heat exchanger thermistor
4.Th3 —
5.Th4 Discharge air thermistor
6.Th5 —
7.Th6 —
4. Outdoor Status Display 1.Unit No. Select the Unit No. you want to check.
2.FAN Tap 1 Fan tap
3.COMP Compressor power supply frequency (Hz)
4.EV1 Degree that electronic expansion valve is
open (pls)
5.SV1 Solenoid valve ON/OFF
6.Th1 Outdoor air thermistor
7. Th2 Heat exchanger thermistor
8.Th3 Discharge pipe thermistor
5. Forced Defrost 1.Forced defrost ON Enables the forced defrost operation.
2.Forced defrost OFF Disables the forced defrost operation.
6. Error Display Selection 1.Warning display ON Displays a warning on the screen if an
error occurs.
2.Warning display OFF No warning is displayed.
3.Error display ON Displays the error on the screen.
4.Error display OFF Displays neither errors nor warnings.
7. Unit No. Transfer 1.Current Unit No. A unit No. can be transferred to another.
2.Transfer Unit No.
8. Sensor Address Display { Unit No.: 0 - 15 Select the Unit No. you want to check.
{ Code
00:
01:
02:
03:
04:
05:
06:
07:
08:
09:
Remote controller thermistor (°C)
Suction air thermistor (°C)
Heat exchanger liquid pipe thermistor (°C)
Heat exchanger gas pipe thermistor (°C)
Indoor unit address No.
Outdoor unit address No.
BS unit address No.
Zone control address No.
Cooling/Heating batch address No.
Demand/low-noise address No.
{ Data The corresponding data will be displayed,
based on the Unit No. and Code selected.
Service Menu Item 2 Remarks
