Si34-803_B List of Electrical and Functional Parts
Appendix 406
Item Name Symbol
Model
RXYQ5PTL RXYQ8PTL
Compressor
Inverter
Type
M1C
JT100GCVDK@SB
OC protection
device
26.5A
STD 1
Type
M2C —
OC protection
device
STD 2
Type
M3C —
OC protection
device
Fan motor
OC protection
device
M1F 2.3A 5.5A
Electronic expansion valve (Main) Y1E Fully closed: 0pls Fully open: 480pls
Electronic expansion valve (Subcooling) Y2E —
Fully closed: 0pls
Fully open: 480pls
Pressure
protection
High pressure
switch
For M1C S1PH OFF: 4.0 MPa ON: 3.0±0.15MPa
For M2C S2PH —
For M3C S3PH —
Low pressure sensor S1NPL OFF: 0.07MPa
Temperature
protection
Discharge gas temperature
protection
(Discharge pipe thermistor)
R3T OFF: 135°C
Inverter fin temperature
protection
(Radiator fin thermistor)
R1T OFF: 93°C
Others Fuse
For main PCB
A1P 250V, 15A
A2P 250V, 3A (PTL : 250V, 15A)
For Noise filter
PCB
F1U —
+0
−0.12
