Icom IC-PCR2500 [11/148] Accessory attachments

INSTALLATION

■ Accessory attachments

D Foot pad

Attach 4 foot pads to the bottom of the IC-PCR1500/

PCR2500 as below.

D Cable hanger

The cable hanger is convenient for ﬁxing a cable to the wall,

etc.

Cable

Clinch the hook.

Remove the protective paper.

Foot pad sheet

(supplied)

IC-PCR2500

Foot pad

Detach 4 foot pads

from the foot pad

sheet.
