i
FOREWORD
Thank you for purchasing this Icom receiver. The IC-PCR1500/
PCR2500
COMMUNICATIONS RECEIVERS
is designed and built
with Icom’s state of the art technology and craftsmanship. With
proper care, this receiver should provide you with years of trou-
ble-free operation.
DD
FEATURES
[Common to both models]
❍ Wide frequency coverage with all mode
receive
❍ Real-time bandscope function
❍ IF shift function
❍
ANF and NR functions are available
(Only when the DSP unit is installed.)
[For IC-PCR2500 only]
❍ Dualwatch operation/Diversity operation
❍ DV and P25 Digital modes are available
(Only when the specific digital unit is installed.)
IMPORTANT
READ ALL INSTRUCTIONS carefully and completely
before using the receiver.
SAVE THIS INSTRUCTION MANUAL— This in-
struction manual contains important operating instructions for
the IC-PCR1500/PCR2500.
EXPLICIT DEFINITIONS
MOUSE PROPERTY SETTING
Depending on the ‘Mouse Property’ setting in the control
panel, main and sub mouse button functions are swapped.
In this instruction manual, the operation is described with
the default setting.
Icom, Icom Inc. and the logo are registered trademarks of Icom Incor-
porated (Japan) in the United States, the United Kingdom, Germany, France,
Spain, Russia and/or other countries.
WORD DEFINITION
R WARNING!
CAUTION
NOTE
Personal injury, fire hazard or electric shock
may occur.
Equipment damage may occur.
Recommended for optimum use. No risk of
personal injury, fire or electric shock.
